TEAR-OUT TAPE UNDERLAYMENT PLYWOOD TROWELS WOOD VINYL CUTTING TOOLS CARPET TOOLS TACK STRIP 40
Portamatic Evolution
10
YEAR
WARRANTY
Porta-Nailer Hammerhead
10
YEAR
WARRANTY
Applications
-- 5/8", 3/4" and 33/32" domestic solid wood flooring
-- 3/8" to 9/16" solid wood flooring (40230 accessory shoe required)
-- 1/2" to 9/16" engineered wood flooring (40230 accessory
shoe required)
SPECIFICATIONS
Operating Pressure Manual
Fastener Capacity 100
Fastener Style 16 Ga “T” Cleats
• Blind nail 3/8" - 33/32" and face nail tongue and groove flooring
using interchangeable shoe attachments
• Multi-hit minimizes fatigue while providing greater impact and
floor tightness - no need to hit tool hard
• Ratcheting ram allows for single or multi-hit, guaranteeing nails
are properly set every time
• Includes extension handle, mallet, angled shoe for 5/8" - 33/32"
tongue and groove flooring, wrenches and rugged carrying case
402A 16 Ga Manual Floor Nailer (1/cs)
40225 Face Nail Shoe (1/cs)
40230 Thin Flooring Shoe (3/8" to 9/16" solid wood floors) (1/cs)
*Not recommended for stranded bamboo products
PORTA-NAILS
Applications
-- 3/8" to 3/4" engineered wood, solid wood, and bamboo flooring
-- 3/8" to 5/8" stranded or woven bamboo products
SPECIFICATIONS
Operating Pressure 80 psi @ 3.8 cfm
Fastener Capacity 110
Fastener Style 18 Ga “L” Cleats
• Unique ram design can be hit at any angle to get closer to the wall
• Cam operated height adjustment
• Quick access to the valve and main piston
• Safety mechanism is built into the base of the tool
418A 18 Ga Floor Nailer (1/cs)
PORTA-NAILS
PORTA-NAILS
10
YEAR
WARRANTY
Applications
-- 5/8", 3/4" and 33/32" domestic solid wood flooring
-- 3/8" to 9/16" solid wood flooring
-- 9/16" engineered wood flooring
SPECIFICATIONS
Operating Pressure 70-115 psi
Fastener Capacity 100-120 pieces
Fastener Style 16 Ga “T” & “L” Cleats / 15.5 Ga Staples
• 3-in-1 design allows for cleats or staples
• Mallet activated to ensure the tightest floor possible
• Integrated safety prevents accidental firing
• Includes mallet, wrenches, pneumatic lubricant, safety goggles,
(2) shoe bases for nailing 1/2" and 3/4" flooring, and carrying case
465SLT 16 Ga 3-in-1 Floor Nailer/Stapler (1/cs)
WARNING: Cancer and Reproductive Harm- www.P65Warnings.ca.gov. See P. 63, *Prop 65 - 5.
3-in-1 Portamatic 465SLT
