Common Items
Nylon Tubing & Fittings
Y Branch
Tee 1/4”
KQ2U07-99
Plug in Reducer
6-> 4mm
KQ2R0604
Nylon Tubing
Out Diameter
is Tubing Size
2020 Fall PARTSALL.COM Toll Free: 866.345.1010
Male w/Nut
4mmx1/8”
C0E001
Particle Filter
Inline 1/4”
F01-02-000
Metric Fitting Size
Inch Fitting Size
Male
A; Tubing
B; Thread
Male Banjo
4mm KQ2H04M5
1/4” KQ2H07-32
Straight Female
1/4”x1/8
KQ2F0734
A
B
Male Fitting
B: #10-32
Tubing Size (A) Thread Size(B)
4 mm 1/8”, 3mm #10-32
6 mm 5mm,1/8, 1/4”
8 mm 1/8, 1/4”
10 mm 1/4, 3/8”
12 mm 3/8”
Tubing Size (A) Thread Size (B)
3/16” 1/8, 1/4”
1/4” 1/8, 1/4”, #10-32
5/16” 1/8, 1/4”
3/8” 1/4, 3/8”
1/2” 3/8”
Male Plug
1/4-> 4mm
31531-1
Tee
Y Union
4,6,8,10,12 mm
3/16,1/4,5/8”
3/8,1/2”
Y Tee
Union Tee
4mm 89230-53
6mm 57230-6
1/4” 89230-04
3/16” KQ2T0500
Run
(Street)
Tee
Union
Double Elbow
Tee, Y & Run Tee
Fitting with Nut
Nylon Tubing
Metric OD ; 4, 6, 8, 10, 12, 15, 16mm
Inch OD ; 1/8, 3/16, 1/4, 5/16, 3/8, 1/2”
Black Rilsan ; 8, 12, 15, 22mm
(Thin Tubing for Dryclean machine)
Elbow
Elbow Banjo
1/4”- 22472
4mm 88115
Elbow
w/Viton Oring
4mmx1/8”
42536-DA
Male
w/Viton Oring
4mmx1/8”
42675-DA
Female Elbow
1/4”x1/4 89110-0404
1/4”x1/8 KQ2LF0734
#10-32
Elbow
Branch Tee & Reducer
Union
4,6,8,10,12 mm
3/16,1/4,5/8”
3/8,1/2”
Double Elbow
4mm-1/8”
2443012
Elbow w/Nut
4mmx5mm
C0E004
