17 SERIES WALL MOUNT
Specicaons
17 Series Wall Mount Indoor Specicaons
Model FTB09AVU FTB12AVU FTB18AVU FTB24AVU
Cooling Capacity
Heang Capacity
Moisture Removal Gallons/Hour
Air Flow Wet 378/345/272/215/165 392/358/282/232/165 578/529/471/418/374 703/654/585/507/437
Air Flow Dry 378/345/272/215/165 392/358/282/232/165 578/529/471/418/374 703/654/585/507/437
Sound Pressure Cooling 41/40/34/29/21 42/41/34/30/22 44/40/38/35/32 46/43/41/37/33
Sound Pressure Heang 41/40/34/29/21 42/41/34/30/22 44/40/38/35/32 46/43/41/37/33
Dimensions 11 11/16 x 35 1/16 x 8 1/4 12 5/8 x 46 1/8 x 9 1/2
Weight 20 lb 30 lb
17 Series Outdoor Specicaons
Model RB09AVU RB12AVU RB18AVU RB24AVU
Sound Pressure Cooling 45 46 51 51
Sound Pressure Heang 45 46 51 51
Operang Range Cooling 50 - 115 Degrees F
Operang Range Heang 5 - 64 Degrees F
Maximum Over Current Protecon 15A 20A
Dimensions 21 5/8 x 25 15/16 x 10 3/4 25 11/16 x 33 11/16 x 12 15/16
Weight 53 lb 57 lb 82 lb 97 lb
Accessories
UL16x36 Condenser Pad
BR440 Wall Bracket
X85003 Condensate Pump 09-18
X87721 Condensate Pump 24+
T18016 Pump Enclosure
Parts & Labor Plan
EWDKEO10PL Transferrable Extended Service Plan
EWDEI10PL 6-10 Year Parts 10 Year Labor
See more installaon supplies & accessories starng on page 9.
12
Specicaons are subect to change at any me. United Refrigeraon is not responsible for changes, errors & omissions.
