The Proper Tools to Keep Your Equipment Moving...
AIR OPERATED LIFTING BAGS & ACCESS.
OSHA
MAXIMUM Force Air Bags.
THIN
CAN
Kit Includes Air Bag and the Following: Model #
Single Safety Relief and Control Valve 12119
Nipple and Industrial Nipple with Valve 12123
20 Feet Air Bag Jack Hose and Couplers 12122
1.800.352.9852 WWW.ESCO.NET 67
one inch clearance.
Lifting capabilities range from 10 Tons to over 70 Tons.
MADE
ESCO Airbags also come in Kit form which includes the Air Bag
(See details below)
Air bags may be used for lifting in several different industries
such as:
Air Bag
Only: Weight Lift
Capacity Dimensions Height Max
Air Bag
Jack Kits Weight
12105 10 lbs.
4.5 kg 13 Tons 15” x 15” x 1”
381mm x 381mm x 25mm
7.5”
191mm 12105K 18 lbs.
8 kg
12107 17 lbs.
8 kg 22 Tons 20” x 20” x 1”
508mm x 508mm x 25mm
9.5”
241mm 12107K 28 lbs.
13 kg
12109 24 lbs.
11 kg 32 Tons 21” x 25” x 1”
534mm x 635mm x 25mm
12”
305mm 12109K 32 lbs.
15 kg
12112 45 lbs.
20 kg 50 Tons 29” x 29” x 1”
737mm x 737mm x 25mm
15”
381mm 12112K 49 lbs.
22 kg
12113 52 lbs.
23 kg 70 Tons 34” x 34” x 1”
864mm x 864mm x 25mm
18”
457mm 12113K 70 lbs.
32 kg
AIRBAG KIT
Air Bag Jacks - Molded Inflatable Jacks
Material Handling • Railroad Work
Mining • Rescue • Military •
Agricultural • OTR Tire Changing
/WWW.ESCO.NET
